Hydraulic Cylinder Test Stands
Overview & Value
The Technics A&T Hydraulic Cylinder Test Stand is a high-performance, modular testing system engineered to evaluate hydraulic cylinders with exceptional accuracy, reliability, and efficiency. Designed for production, laboratory, and repair applications, the platform supports comprehensive functional and endurance testing of single-acting and double-acting hydraulic cylinders across a wide range of operating conditions.
The system is configurable to accommodate varying cylinder sizes, stroke lengths, pressure ratings, and flow requirements. Technics Assembly & Test collaborates closely with customers to develop customized testing solutions that align with performance specifications, operational goals, and budget requirements.
Integrating advanced automation, precision hydraulic controls, and intelligent data acquisition, the CT-25A enables operators to execute repeatable test procedures safely and efficiently while maintaining high levels of accuracy and productivity.
The Ultimate Solution for Hydraulic Cylinder Testing
Engineering Solutions
From concept to commissioning, our multidisciplisiery engineering team delivers integrated solutions
that meet industry standards and exceed expectations.
Specifications:
- Pressure up to 6,000 PSI
- Stroke lengths customizable to application requirements
- Flow capacities designed for high-speed cycling and testing
- Power up to 600 HP
Multistage Filtration:
- Kidney loop filtration system
- High-pressure filtration system
- Integrated contamination particle counter
Cylinder Testing Capabilities:
- Cylinder leakage testing
- Pressure holding and proof testing
- Stroke and positioning verification
- Speed and cycle testing
- Cushion testing and adjustment verification
- Drift and bypass testing
- Endurance and life cycle testing
- Force measurement and load simulation
- Single-acting and double-acting cylinder testing
High-Performance and Efficiency:
- High-accuracy sensors for pressure, position, flow, force, and temperature measurement
- Servo-controlled hydraulic systems for precise motion and pressure control
- Variable speed drive technology for energy-efficient operation
- Precision proportional valves with rapid dynamic response
- Integrated digital data acquisition
- High-speed charts and graphs
- Automatic report generation
- Barcode scanning and product traceability
- Data files and reports saved to local drives and company networks
- Vision systems for external leak detection and post-test analysis
Safety Features:
- Intelligent alarms and warnings
- Safety-rated high-pressure relief valves
- Interlocked safety door system
- Impact-resistant polycarbonate safety shield
- Emergency stop circuitry
- Soft-start and controlled pressure ramping
- Sump pump for hydraulic oil recovery
Intuitive Operator Interface:
- Large touchscreen monitors with VESA mount positioning
- Simple navigation between multiple testing windows
- Password-protected setup screens
- Dedicated screens for individual test routines
- Front office integration capabilities
Applications:
Mobile Applications
Agriculture | Construction | Mining | Railway | Marine | Concrete | Off-Highway Equipment
Industrial Applications
Manufacturing | Material Handling | Packaging | Oil & Gas | Energy | Steel Mills | Plastics
